What is a punching plate? New height of appearance in the metal world.

Views:575 Author:Site Editor Publish Time:2021-09-23 14:08:12 Orgin:Site
share



Punching plate has been an indispensable metal product in our life and production. No matter where we go, we can see the shadow of punching plate. The most used punching plate belongs to exterior wall decoration. The metal perforated plate used in buildings generally takes aluminum plate as the base material, and various hole types set off different characteristics.




The punching plate has the advantages of light weight, good rigidity, high strength, reasonable structure and long service life. It has rich visual effects in different light, different environments and different observation angles. It is used in various occasions to highlight elegant temperament and extraordinary personality. Therefore, the punching plate quickly stands out among many materials in the application of building skin decoration.


01.


Power faction delayed by name


The name of punched plate is not brilliant at first, but it is absolutely amazing to use.

The power faction delayed by the name.

As the name suggests, a punched plate is a metal plate with holes.

The materials are mostly stainless steel plate, aluminum plate, iron plate, copper plate, etc.

It is processed by stamping machine or milling machine. It has the characteristics of long service life and no deformation.




The hole size and pattern of the punching plate can be processed as required.

Design holes of different sizes, densities and shapes to form different translucent line of sight effects.



Different hole patterns of perforated plate▼




The hole types of punching plate include:rectangular hole,square hole,diamond hole,round hole,long round hole,hexagonal hole.

Cross hole, triangular hole, long waist hole, plum blossom hole, fish scale hole, pattern hole, splayed net, herringbone hole

Five pointed star shaped hole, irregular hole, bulging hole, special-shaped hole, shutter hole, etc.



There are two commonly used perforation methods in modern times:


「CNC punch punching」


CNC punch is a common perforation method,

Punch holes on the metal surface by means of machine tool stamping.▼






Stamping process can be used in metal screen

And rapid perforation on a large area of the panel.▼






「Laser perforation」


Laser perforation is the latest development of perforation technology,

It is also a relatively expensive and complex technology,

Higher accuracy and randomness.▼




02.


He is a good-looking and powerful man in the metal world


In recent years, the use frequency of punching plate is higher and higher.

Whether it is the outer skin of the building, the indoor pattern partition, or the landscape device.

It can be seen everywhere. Its advantages are as follows:




「Changeable hole aesthetics」


The most direct appearance feature of perforated metal plate is porosity.

Porosity means that the two parts of the space separated by the skin have permeability to each other, breaking the inherent boundary between the inside and outside.

Truly achieve the mutual penetration of internal space and external space.



Gradient hole -- Edo bathing beach in Japan and Japan

The perforated plates with wavy patterns gradually disappear from bottom to top, reflecting the aesthetic taste of the Edo era in Japan.







Designed by Kubo Tsushima Architects



Divergent hole - Jingzhai (Beijing)









Designed by : Tao Lei architectural firm



Round hole -- Huangyan store of Duoyun Academy (Taizhou, Zhejiang)

A continuous white perforated aluminum wall wraps the building.

(by controlling the perforation rate, a layer of rain and fog will be formed on the facade),

Creates a quiet and pleasant visual subtraction. A cloud rises on the Bank of the river, and the readers of the bookstore are in the cloud.





Designed by Wutopia Lab



Green plant silhouette punching board -- Xing ● she (Beijing)






Designed by : Coston, Canada


Silk perforated plate -- Hushuguan culture and Sports Center (Suzhou)

Hushuguan Town, where the case is located, has been an important town in the south of the Yangtze River since ancient times,

The thin metal perforated plate forms the outer skin of silk, with a flexible shape,

The fine and light texture is not difficult to associate with the famous Hushuguan silk.





designed by:Zhongheng design



Ripple of water -- lolly Laputan children's Restaurant (Dalian)





Designed by:Wutopia Lab



Eryou Bookstore - (Shanghai)

Eryou bookstore is located in the network red building Hengji Xuhui world designed by nuville,

Wine red perforated plates form holes to create a rich spatial experience,

There are surprises everywhere and scenery step by step.






Designed byWutopia Lab


「Mottled light and shadow effect」


The perforated plate will produce rich light and shadow changes under the irradiation of sunlight or light.

This effect will make the building have a unique and flexible visual effect, and make the relationship between the main body of the building and the outer skin more hazy, with a sense of integrity and hierarchy.

The change of hole size, aperture and perforation rate will also produce different light and shadow effects.





Jin Co Ltd office building



Designed by:Aoki Jun








Nike global headquarters La garage (USA)

The building mainly embodies the most key sports theme in Nike design culture:

The exquisite exterior wall composed of perforated metal plate and glass is given a specific inclination angle,

While providing shelter for the vehicle, it also creates a dynamic look and feel.






设计:SRG Partnership


Yanjiao Campus Library of Central Academy of Fine Arts

The appearance of the entrance is simple, lively

Hazy white perforated panels with bright orange,

It is connected with the gray and white facade of the original building,

It also forms a strong symbol, and the perforation forms a tree pattern.





Designed by : He Wei studio of Central Academy of fine arts



Domino Pavilion (Shenzhen)

There is no wall in this building, but only 24 large iron doors that can be turned by people.

The space is flexibly enclosed by metal revolving door and glass partition wall, perforated metal plate and mottled wall.






Designed by : original design and research center of Shenzhen University


Fame awareness Center (Wuxi)

The white perforated plate holes in the atrium adopt organic shapes to echo the overall interior design.





Designed by : Shanghai Lianchuang Design Group Co., Ltd


「Novel effects of different panel combinations」


Perforated metal plates can be made into different shapes and sizes for different connection combinations according to different needs.

The combination mode is rich and changeable.


Corrugated perforated aluminum plate -- Vanke Wuyang Boyu (Guangzhou)

Divide the building volume with light rhythm and jumping blocks to form a dialogue with the city.







Designed by : inter building design



Positive and negative arc splicing punching plate - Qizhong garden office building (Foshan)

The facade adopts the staggered splicing mode of positive arc / reverse arc of punched plates to create a bright and bright architectural image.






Designed by : All buildings



Different transparency layout combinations - Munk Museum (Oslo)

The facade adopts perforated aluminum plates with different transparency to create a mysterious and fleeting visual experience.






Designed by :estudio Herreros



North Greenwich Metro

The thickened perforated wall is folded, showing a subtle dynamic effect like a veil, bringing a changing look throughout the day.





Designed by :Neiheiser  Argyros


「Temperature control and noise reduction characteristics」


The perforated plate resonance sound absorption structure has the effects of heat insulation, temperature control, sound absorption and noise reduction.



MGB head office (India)

The screen wall system composed of metal perforated plates can filter sunlight,

In this hot and dry area, the indoor temperature can be adjusted,

At the same time, it gives a lively and lightweight geometric pattern,

Make it a unique sight on the street.






Designed by :Spacefiction Studio


IMAS Art Center (Beijing)






Designed by : Architectural camp design studio



Breathing forest Apartments (UK)

The "breathing" perforated plate can introduce natural wind into the whole apartment.

A computer control panel is set behind the perforated plate, which can be opened or closed according to the internal temperature of the apartment,

And it can avoid the sudden strong wind interfering with the quiet indoor environment.




Designed by :Tonkin Liu


The article reprints "design materials"
